To Suit Nissan Patrol GU - 146L Replacement Fuel Tank

GET A QUOTE
Enquiry
IMPORTANT! Check OE fill hose size, if same either end you need fill hose from later model (02/2000 onward) Part No 17228-VB00. If Kaymar rear bar fitted, extra labour required. WILL NOT FIT WITH ARB REAR WHEEL CARRIER
Sorry no Image available

Specifications

Part NumberNPGUR
Tank TypeReplacement
Tank Note
On 1998-2000, check the OE fill hose size, if it is the same both ends, you will need the hose from the later model (02/2000 onwards), the part number #17228-VB00.
ExhaustSTANDARD
LocationBehind Rear Axle
Fill PointSTANDARD
Capacity146 Litres
Fitting Time3 Hrs
Fitting Notes
WILL NOT FIT WITH ARB REAR WHEEL CARRIER
Relocate SpareNO
Vehicle Notes
Replaces Main Tank
NPGUR BrochureNPGUR Installation Instructions

Shipping Dimensions

Height52 cm
Width65 cm
Length110 cm
Weight48 kg

Applicable Vehicles

MakeModelStart YearEnd YearSeriesFuelBodyDriveRelocate Spare
To Suit NissanPatrol19982016GUDieselWagon4WDNO
Replaces Main Tank
To Suit NissanPatrol19982014GUPetrolWagon4WDNO
Replaces Main Tank
To Suit NissanPatrol19982016GUDieselCoil Cab Chassis4WDNO
Replaces Main Tank
To Suit NissanPatrol19982014GUPetrolCoil Cab Chassis4WDNO
Replaces Main Tank
